Automann 46-1345 S/L Air Beam L/H 1/SB
Sale
Automann

Automann 46-1345 S/L Air Beam L/H 1/SB

$580.00
$410.00 In Stock Pre-Order Sold out
Notify when available

3-7 Days Delivery

No Hassle Return Policy

30-Day warranty

  • Description
  • Shipping and Refund
  • Reviews
Brand: Automann
Product Level: Fleet Standard
Description:
                       Driver Side
                       Uses MCB850 Centerbolt
Applications: Freightliner
Unit Size: 1
Weight: 70.25 lbs
Pkg. Dims (in): 45.22 X 6.19 X 10.45

Specifications

Attribute Value
Spring Type Air Beam
Spring Eye 1
Eye Type (S.E./L.E.) STD/---
Width 3
S.E. (A) 25-3/8
L.E. (B) 18-1/2
Bushing A End (S.E.) RB268, MR782
Bushing B End (L.E.) - - -
Nos. Leaves SINGLE
Arch (C) 1-19/32
Capacity 20000
MFG Freightliner
Notes (B. O. M) 3X1/2.000, SB/250*25-3/8X18-1/2 C:1-19/32 RB268/- - - <B>MR782(Bushing Flange Toward Frame Rail)</B>
Center Bolt Size 1/2 X 3
Center Bolt Head Size 3/4D X 3/4H



Includes


Automann # Product Name QTY
MR782 Silent Block Freightliner/IHC 1
MFL129 Shock Bracket RH/LH Freightliner 1
MCB850 Center Bolt 5/8in X 3.0in Freightliner 1



Where Used

Name Type
Freightliner Rear Fas Airliner lI (Freightliner &amp; Sterling) Suspension



Cross Reference

Name Part Number Notes
Freightliner 1616413000 Single Leaf Air Beam L/H 1/Sb
Freightliner 16-16413-000 Single Leaf Air Beam L/H 1/Sb
Freightliner A1616413000 Single Leaf Air Beam L/H 1/Sb
Freightliner A16-16413-000 Single Leaf Air Beam L/H 1/Sb
Hendrickson 51922 Single Leaf Air Beam L/H 1/Sb
Hendrickson 51988 Single Leaf Air Beam L/H 1/Sb
Hendrickson 52358 Single Leaf Air Beam L/H 1/Sb
